Performance

Cooling
Capacity
Btu/h 18,000
kW 5.3(2.0-5.6)

Input kW 1.59(0.42-1.84)
SEER   6.1
EER   3.33
Energy class   A++
Heating
Capacity
Btu/h 20,000
kW 5.9(3.0-6.0)

Input kW 1.43(0.64-1.64)
SEER   4.0
EER   4.12
Energy class   A+

Physical data

Aiflow (High speed) m3/h 900
Noise level (MAX)
Power level   46-58
Pressure level  dB (A) 36-45
Net simension(WxHxD)
Body mm 840x230x840
Panel mm 950x50x950
Net weight
Body kg 25
Panel kg 5.4
Packing dimension(WxHxD)
Body mm 920x265x920
Panel mm 1030x105x1030
Gross weight
Body kg 30
Panel kg 8.0

Piping data

Diameter
Liquid side mm Φ6.35
Gas side mm Φ12.7
Drain pipe   mm DN25
