Technical Specifications(R32-DC Inverter)
Type cooling only cooling only cooling only cooling only
Control type remote remote remote remote
Rated cooling capacity   Btu/h 9000(3583~11942) 12000(3412~12624) 18000(5118~19450) 22000(5118~22520)
  W 2690 3550 5150 6400
EER for cooling Btu/h.w;  W/W 2.83 3.02 2.8 2.89
Moisture removal Liters/h 0.8 1.0 1.5 2.6
Indoor noise level at cooling High dB(A) 38 40 45 48
Med. dB(A) 35 35 / 43
Low dB(A) 31 32 / 38
Outdoor noise level dB(A) 50 52 54 53
Electrical Data
Power supply 220-240V~/50Hz/1P 220-240V~/50Hz/1P 220-240V~/50Hz/1P 220-240V~/50Hz/1P
Voltage Range V 165~265 165~265 165~265 165~265
Rated current Cooling A 4.0（1.3~6.0） 5.8(1.0~8.0) 8.2 ( 2.3  ~ 9.3 ) 9.5 ( 1.6  ~ 13 )
Rated input Cooling W 950（220~1250） 1250(270~1600) 1800( 500 ~ 2100 ) 2100( 300 ~ 2550 )
Max current  A 6 8 10 13
Max input W 1250 1600 2100 2550
Refrigerating System
Refrigerant/Charge Gram R32/290 R32/400 R32/630 R32 / 720
Compressor Type Rotary Rotary Rotary Rotary
MFG RECHI GMCC HIGHLY GMCC
Evaporator 3-bend 3-bend 3-bend 3-bend
Indoor coil d.Fin type (code)   Hydrophilic Hydrophilic Hydrophilic Hydrophilic
e.Tube outside dia.and type  mm Ø7 Inn. Grv. Ø5 Inn. Grv. Ø7 Inn. Grv. Ø7 Inn. Grv.
Condenser single-arranged single-arranged single-arranged double-arranged
outdoor coil e.Tube outside dia.and type  mm Ø5 Inn. Grv. Ø7 Inn. Grv. Ø7 Inn. Grv. Ø5 Inn. Grv.
Indoor air circulation  Cooling/heating m3/h 500 490 810 980
Indoor fan type Cross Flow Cross Flow Cross Flow Cross Flow
Indoor fan speed H/M/L Cooling rpm 1300/1200/1120/1050/980/900/800 1250/1150/1000/950/900/850/600 1350/1250/1050/850/750 1270/1200/1100/1000/920/850/750
Indoor fan motor output W 14（BROAD OCEAN） 14 45 45（BROAD OCEAN）/45（WELLING）
Outdoor fan speed rpm 1000 1000 860 880
Outdoor fan motor output W 33(weiling) 33(weiling) 31 44（BROAD OCEAN)/39(WELLING)/47(Tongde)
Connections
Refrigerant coupling
Connecting Pipe Gas Inches 3/8” 3/8” 1/2” 1/2”
Liquid Inches 1/4” 1/4” 1/4” 1/4”
Connecting Wiring Size x Core number 4×1.0 4×1.0 4×1.5 4×1.5mm2
Others
Suitable area m2 9~16 15-23 20~35 27~45
Net dimensions Indoor mm 698×255×190 777×250×201 910×294×206 1010×315×220
(W x H x D) Outdoor mm 712×276×459 712×276×459 795×305×549 853×349×602
Net weight Indoor kg 7.5 8 9 13
Outdoor kg 20 21 25 30
Packing dimensions Indoor mm 764×325×257 850×320×275 979×372×277 1096×390×297
(W x H x D) Outdoor mm 765*310*481 765*310*481 835×340×585 890×385×628
Gross weight Indoor kg 9.5  10 12 16
Outdoor kg 23 24 28 33/34  (with pipe)
Loading Capacity w/o pipe 40’HQ 372 360 235 200
